Rapid ShipAluminum Mortise Geared Hinges

  • Any Door Material
  • Heavy Duty for high frequency 1 3/4” doors or heavy medium frequency doors up to 450lbs.
  • 117FM (Heavy Duty), 217FM (Heavy Duty)
Additional Resources
Clear
    Reset options

Description

CONCEALED/MORTISE LEAF HINGES

  • Any Door Material
  • Heavy Duty for high frequency 1 3/4” doors or heavy medium frequency doors up to 450lbs.
  • 117FM (Heavy Duty), 217FM (Heavy Duty)
MODEL LENGTH SCREW COUNT CLEARANCE
C (Clear Anodized) D (Duro Anodized) IN CM DOOR JAMB
117FMC-83 117FMD-83 83 210.8 19 19 5/16” (8mm) hinge side plus standard lockside clearance
117FMC-95 117FMD-95 95 241.3 21 21
117FMC-120 117FMD-120 120 304.8 27 27
217FMC-83 217FMD-83 83 210.8 19 19
217FMC-95 217FMD-95 95 241.3 21 21
217FMC-120 217FMD-120 120 304.8 27 27
*Note: First 3 numbers = (Product #), FM = (Full Mortise), C or D = (Finish), 83, 95 & 120 = (Length)
FASTENERS:
(Self-Tapping Screws)
  • All fasteners as No. 12-24 x 1/16” Type C, FHUC
  • Heavy Duty Hinges – 10 required for each leaf
LENGTH OPTIONS: 83”, 95” & 120”
DOOR REINFORCEMENT:
  • None needed to 200 lbs
  • Use 16 gauge channel over 200 lbs
FRAME REINFORCEMENT:
  • None needed to 200 lbs
  • Use 16 gauge channel over 200 lbs
FIRE RATING: Up to 3 Hours
SPECIAL FEATURES:
  • For new construction
  • For renovation with new door and / or frames
  • No mortising of doors or frames required
  • Will cover hinge cut outs in frames
  • Flush mount no inset
  • Frame and door leaf alignment ribs for proper hinge location
STANDARD FINISHES:

  • C (Clear Anodized Aluminum), D (Duro Anodized Aluminum)
SPECIAL ORDER FINISHES:

  • PW (Painted White), G (Gold Anodized Aluminum), BL (Black Anodized Aluminum)
