5000 SERIES GRADE 2 EXIT DEVICE
International Door Closers IDC 5000 Series Exit Devices meet the Life and Fire Safety Codes as prescribed by UL and ANSI / BHMA 156.3 standards. These durable devices are designed for both standard and commercial applications. The 5000 Series were tested and approved by Underwriters Laboratories (UL, USA and ULC, Canada) and listed to comply with UL 10C, and Uniform Building Code Standard 7-2, “Fire Test of Door Assemblies” (1997).
Additional Resources
Description
5000 SERIES GRADE 2 EXIT DEVICE
International Door Closers IDC 5000 Series Exit Devices meet the Life and Fire Safety Codes as prescribed by UL and ANSI / BHMA 156.3 standards. These durable devices are designed for both standard and commercial applications. The 5000 Series were tested and approved by Underwriters Laboratories (UL, USA and ULC, Canada) and listed to comply with UL 10C, and Uniform Building Code Standard 7-2, “Fire Test of Door Assemblies” (1997).
FEATURES
- All devices are non-handed design
- Auxiliary guarded latch deadlocks latch bolt automatically locks when the door is closed
- High shock-resistant latching mechanical design for protection from vandalism
- All inside components are made of high rust-resistant alloy or heavy electroplated steel
- Baked powder coating, electroplated or architectural base finishes are used on all exposed surfaces
- Outside trims are provided by rose and escutcheon lever or knob in a variety of styles
- All trim, features a through-bolted design to the devices that allow easy installation but not to compromise on security
- With a dogging mechanism, users have a choice of hex-key or cylinder operated design for a positive push-pull door action during peak traffic time
5510 SERIES RIM EXIT DEVICE & 5530 SERIES SVR EXIT DEVICE
These two series models are wide stile design, UL listed Panic Hardware or Fire Exit Hardware.
Rim Type- Ideally suited for:
- Any single exterior doors
- Any panic or fire rated interior single door and all exit doors in factories, hospitals, apartments, office buildings
- Indoor parking lots
SVR Type- Ideally suited for:
- Any pairs of emergency exit doors
- Pairs of doors in cross-corridors
- Double egress applications
- Passage doors in hospitals, factories or any public buildings
5610 NARROW DESIGN PANIC RIM DEVICE & 5630 NARROW DESIGN PANIC SVR DEVICE
These two models are narrow stile design, UL listed Panic Hardware
Rim Type and SVR Type Both Types- Ideally suited for:
- Glass door
- Aluminum entrance doors
- Passage doors
- Full glass doors in stores, resorts and hotels
MODEL 5510S PANIC-RATED RIM EXIT DEVICE – For wide stile and flush doors use
MODEL 5510F FIRE-RATED RIM EXIT DEVICE – For wide stile and flush doors use
Application
- For use on single or double doors with mullion (Fire rated device must use on 4’ x 8’ single or up to an 8’ x 8’ double fire labeled doors).
- Fits for 1 3/4” (44mm) thick standard RHR or LHR hollow metal doors & wood doors Other than standard an 1 3/4” is available but specify door thickness when ordering.
- Minimum Stile width: 3 1/2” (90mm)
 |
531 Strike Shim Furnished with 532 Strike together made if steel and is plated. This shim is 1/8” thick and is used to prepare doors with a 1/2” stop. This will correct the distance between the device latch and the surface. If the frame has a 5/8” stop a shim is not needed. |
 |
532 Panic Rim Strike Surface applied standard on 5000 Series panic rim exit devices. Stainless Steel with a plated roller. |
 |
533 Fire Rim Strike Surface applied. Standard on 5000 Series fire rim devices. It is 100% stainless steel including a roller. |
Specifications
| Device Head Cover | Stainless Steel, nonferrous alloy |
| Chassis | Steel plated |
| Mechanism Housing | Steel or Stainless Steel |
| Push Bar | Steel or Stainless Steel |
| End Cap | Steel or Stainless Steel |
| Latch Bolt | 100% Stainless Steel, dead locking type with an 11/16” throw |
| Deadlocking Latch | 100% Stainless Steel with 5/8” (16mm) throw |
| Strikes | 531 & 532 Rim (panic rated) 533 Rim (fire rated) |
| Handing | Non-handed |
| Mounting Fasteners | Machine screws furnished standard Sex Nut & Bolt (SNB) are required for wood doors. Order SNB separately including standard. |
| Dogging* | Hex key dogging standard (Allen-type key furnished) |
| Dogging Options | Cylinder dogging or less dogging |
| Finish | US28(689) and US20A(690) |
| Dimension | See Spec. Sheet |
| Device Length | See Spec. Sheet |
| UL Listed | For Panic Hardware, see model 500SA For Fire Exit Hardware, see model 510AF |
*Fire rated SVR device has no mechanical dogging. (Dogging device is not permitted on fire-rated exit device)
MODEL 5510S PANIC-RATED RIM EXIT DEVICE –
For narrow stile exit doors made from Aluminum, Metal (HM) or Wood
Application
- For use on single doors or double doors with mullion (Fire rated device up to 4’x8’ single or 8’x8’ double fire labeled doors.
- Fits for 1 3/4” (44mm) thick standard non- handed or hollow metal or wood doors, other than standard 1 3/4” is available, specify door thickness.
- Minimum Stile width : 2 1/2” (63mm)
|
531 Strike Shim Furnished with 532 Strike. This shim is 1/8” thick for prepared doors with 1/2” stop. It is used to obtain correct distance between the latch and the surface applied strike, when the stop is 1/2” high. If the frame has a 5/8” stop the shim is not required. Strike shim is steel and plated. |
|
532 Panic Rim Strike Surface applied. Standard on 5000 Series panic rim exit devices. Stainless steel with a plated roller. |
Specifications
| Device Head Cover | Stainless Steel, nonferrous alloy |
| Chassis | Steel plated |
| Mechanism Housing | Steel or Stainless Steel |
| Push Bar | Steel or Stainless Steel |
| End Cap | Steel or Stainless Steel |
| Latch Bolt | 100% Stainless Steel, dead locking type with an 11/16” throw |
| Deadlocking Latch | 100% Stainless Steel with 5/8” (16mm) throw |
| Strikes | 531 & 532 Rim (panic rated) |
| Handing | Non-handed |
| Mounting Fasteners | Machine screws furnished standard Sex Nut & Bolt (SNB) are required for wood doors. Order SNB separately including standard. |
| Dogging* | Hex key dogging standard (Allen-type key furnished) |
| Dogging Options | Cylinder dogging or less dogging |
| Finish | US28(689) and US20A(690) |
| Dimension | See Spec. Sheet |
| Device Length | See Spec. Sheet |
| UL Listed | For Panic Hardware, see model 500SA For Fire Exit Hardware, see model 510AF |
*Fire rated SVR device has no mechanical dogging. (Dogging device is not permitted on fire-rated exit device)
MODEL 5530S PANIC-RATED SVR EXIT DEVICE – For wide stile and flush doors use
MODEL 5530F FIRE-RATED SVR EXIT DEVICE – For wide stile and flush doors use
Application
- For use on all single doors or double doors where two-piont latch is desirable (inactive leaf of double door). Fire rated device must use on 4’ x 8’ single or 8’ x 8’ double fire labeled doors.
- Fits for 1 3/4” (44mm) thick standard non-handed hollow metal and wood doors, other than standard 1 3/4” is available but specify door thickness when ordered.
- Minimum Door Stile width: 3 1/2” (90mm)
 |
534 Top Strike Applied to surface of stop. Hardened steel and plated. |
 |
537 Bottom Strike Applied to surface of floor. Nonferrous alloy and plated. |
Specifications
| Device Head Cover | Stainless Steel, nonferrous alloy |
| Chassis | Steel, stainless steel |
| Mechanism Housing | Steel or Stainless Steel |
| Push Bar | Steel or Stainless Steel |
| End Cap | Steel or Stainless Steel |
| Latch Bolt | 100% stainless steel, 1/2” (13mm) throw |
| Latch Case Covers | Steel, stainless steel |
| Vertical Rods | Tubular aluminum with rod guides |
| Strikes | Top 534, Bottom 537 |
| Handing | Non-handed |
| Mounting Fasteners | Machine screws furnished standard, Sex Nut and Bolt (SNB) are required to use for wood doors. Order SNB separately. |
| Dogging* | Hex key dogging standard (Allen-type key furnished) |
| Dogging Options | Cylinder dogging or Less dogging |
| Finish | US28(689) and US20A(690) |
| Dimension | See Spec. Sheet |
| Device Length | See Spec. Sheet |
| UL Listed | For Panic Hardware, see model 900SA and Fire Exit Hardware see model 917A |
*Fire rated SVR device has no mechanical dogging. (Dogging device is not permitted on fire-rated exit device)
MODEL 5630S PANIC-RATED SVR EXIT DEVICE –
For narrow stile and flush doors use
Application
- For use on all single or double doors where two-point latch is desirable (inactive leaf of double door in specialty). Fire rated device must be use on 4 ’x 8” single or 8’ x 8” double fire labeled doors (max. size).
- Fits for 1 3/4” (44mm) thick standard RHR or LHR hollow metal door and wood doors, other than standard 1 3/4” is available but specify door thickness when ordering.
- Minimum Door Stile width: 2 1/2” (63mm).
|
534 Top Strike Applied to surface of stop. Hardened steel and plated. |
|
537 Bottom Strike Applied to surface of floor. Nonferrous alloy and plated. |
Specifications
| Device Head Cover | Stainless Steel, nonferrous alloy |
| Chassis | Steel, plated |
| Mechanism Housing | Steel or Stainless Steel |
| Push Bar | Steel or Stainless Steel |
| End Cap | Steel or Stainless Steel |
| Latch Bolt | 100% stainless steel, 1/2” (13mm) throw |
| Latch Case Covers | Steel, stainless steel |
| Vertical Rods | Tubular aluminum with rod guides |
| Strikes | Top 534, Bottom 537 |
| Handing | Non-handed |
| Mounting Fasteners | Machine screws furnished standard, Sex Nut and Bolt (SNB) are required to use for wood doors. Order SNB separately. |
| Dogging* | Hex key dogging standard (Allen-type key furnished) |
| Dogging Options | Cylinder dogging or Less dogging |
| Finish | US28(689) and US20A(690) |
| Dimension | See Spec. Sheet |
| Device Length | See Spec. Sheet |
| UL Listed | For Panic Hardware |
*Fire rated SVR device has no mechanical dogging. (Dogging device is not permitted on fire-rated exit device)
